FLUKE 771 - 4-20 mA process multimeter clamp
FLUKE 771 - 4-20 mA Process Clamp MeterFLUKE 771 - 4-20 mA Process Clamp MeterFLUKE 771 - 4-20 mA Process Clamp Meter
FLUKE-771
Deadline 2 weeks
Characteristics of Fluke 771, 772 and 773:
- Exceptional accuracy of 0.2%
- Resolution and sensitivity of 0.01 mA
- Measuring signals from 4 to 20 mA without "breaking the loop"
- Measure mA signals for PLC and control system analog I / O
- Dual backlit display with both mA measurement and percent of 4-20 mA
- Service Spotlight illuminates hard to see wires in dark
- Detachable clamp with extension cable for measurements in tight spaces
- Measure 10-50 mA signals in older control systems using the 99.9 mA range
- Automatic change of the 4-20 mA output for remote testing
- The energy saving features, the automatic disconnection of supply and sprinkler backlight can increase the life of batteries
- Hold function captures and displays changing measurements
Additional Features multimeters 772 and 773:
- measuring signals from 4 to 20 mA with internal measurement circuit
- MeasureSimultaneous current (mA) circuit with a DC 24 V loop for food and testing transmitters
- Signal generation from 4 to 20 mA for testing control systems I / O or testing of current / pressure
- Linear ramp mA output or output in increments of 25%
- Automatic change of the 4-20 mA output for remote testing
Features specific to the multimeter 773:
- DC voltage measurement to check the power of 24 V voltage signals or I / O
- DC voltage generation devices for testing input receiving a signal from 1 to 5 V or 0 to 10 V
- Scaled mA output provides a signal corresponding to signal continuously mA 4 to 20 mA mA measured by the clamp
- Allows connection to a mA signal recording device separated without breaking the loop
- MA output signal to record the signal from 4 to 20 mA using a digital multimeter or other device without breaking the loop
- Input / output mA: simultaneous measurement of mA signal with the forceps and signal generation mA
- Application of a mA input signal to a device and measuring the output signal of 4-20 mA devices such as valves or disconnects mA
- Linear ramp output voltage or output by 25% increments
- Automatic updating of the output voltage for remote testing
presentation of different models and their characteristics:
What is the difference between the models 77X?
| Diameter of measurable conductor |
| ||||
| Operating Temperature |
| ||||
| Storage temperature |
| ||||
| Operating Humidity |
| ||||
| Operating Altitude |
| ||||
| IP level |
| ||||
| Dimensions |
| ||||
| Weight |
| ||||
| Vibrations |
| ||||
| Shocks |
| ||||
| EMI / RFI |
| ||||
| Temperature Coefficient |
| ||||
| Batteries, life |
| ||||
| Warranty |
|
| Caracfunctional characteristics | |||||||||
| Measure mA (measured by clamp) 771/772/773 |
| ||||||||
| MA measure (in series with Plugs) 772/773 |
| ||||||||
| Generation mA (maximum source capacity: 24 mA to 1000 ohms) 772 / 773 |
| ||||||||
| Simulation mA (maximum voltage 50 V DC) 772/773 |
| ||||||||
| Generation voltage (max drive current of 2 mA) 773 only |
| ||||||||
| Voltage measuring only 773 |
| ||||||||
