Technology "Voltbeat" self-test for continuous monitoring of the operation
Once the detected voltage, the tip and illuminates the device emits a beep.
CAT IV 1000 V for added protection
Extended voltage range: 0 to 1000 VAC or 200 VAC VAC 1000 VAC (depending on model)
Also available: 20 VAC to 90 VAC (model for control circuit)
2 year warranty
Analyze the electrostatic field generated by a fixed voltage AC through the isolation and without direct contact with the connector exposed. The tip glows red and the unit beeps (if turned on) to indicate the presence of a voltage.
Ranges of voltage sensing
Ratings: 90 VAC to 1000 VAC or 200 VAC to 1000 VAC (depending on model), 45 Hz to 405 Hz, other: 20 VAC to 90 VAC model for control circuit
Flat or round (depending on model)
High intensity red LED
Compliance with safety standards
c CSA us, CE, C-Tick
1000 V CAT IV
-10 ° C to 50 ° C
0% to 95%
(0 ° C to 30 ° C)
0% to 75%
(30 ° C to 40 ° C)
0% to 45%
(40 ° C to 55 ° C)
2 AAA alkaline batteries included
Note: The device is not sensitive to random electrostatic discharge.
