Reference: FLUKE-975V

More info
Avis

Fluke 975V measure the following data:

Temperature
Air velocity
Humidity
CO ₂
CO

Use the tool to measure the air quality Fluke 975 to:

Meet the expectations of the occupants for their welfare
Check operation of HVAC control systems of a building
Determine ventilation systems adapted instead
Control the flow and air velocity
Check for leaks dangerous carbon monoxide
Perform measurements inside pipes
Optimize HVAC systems to better manage energy costs

The Fluke 975 offers an unparalleled feature set to technicians performing maintenance on industrial equipment and HVAC systems. It saves them time, to obtain accurate measurements and meets customer expectations through ease of use and durability.

Measures, records and displays simultaneouslyhas temperature, humidity, CO ₂ and CO on its backlit LCD display illuminated
Measurements of flow and air velocity using a single button with the probe *
Dew point temperature and wet bulb
Calculating the percentage of outside air
Feature on-site calibration of CO ₂ and CO
Auto-start test
Automatic backlight
Automatic compensation for barometric pressure changes
Gives the min / max / average of all measurements and calculated
MUI
Metric and imperial
Audible and visual threshold defined by
High capacity data recording intermittent or continuous, downloadable to a computer via USB
Keypad lock for added security
Forms included FlukeView ®

* Included in the Fluke 975V, optional with Fluke 975

Specifications measured

Temperature

Range:	-20 ° C to 50 ° C
Display resolution:	0.1 ° C
Accuracy:	± 0.9 ° C to 40 ° C to 60 ° C ± 0.5 ° C to 5 ° C to 40 ° C ± 1.1 ° C from -20 ° C to 5 ° C

Relative Humidity

Range:	10% to 90% RH, noncondensing
Display resolution:	100%
Accuracy:	± 2% RH (10% RH to 90% RH)

Air velocity

Range:	50 fpm to 3000 fpm 0.25 m / sec to 15 m / sec
Display resolution:	1 fpm (0.005 m / sec)
Accuracy:	± 4% or 4 fpm * ± 4% or 0.02 m / sec * whatever the highest value * Accuracy specification only valid for higher speed measurementsat 50 fpm.

Range:	0-500 ppm
Display resolution:	1 ppm
Accuracy:	± 5% or ± 3 ppm, regardless of the highest value at 20 ° C 50% RH

C0 ₂

Range:	0 to 5 000 ppm
Display resolution:	1 ppm
Accuracy:	Warm Up Time: 1 min (5 minutes for complete specifications) 2.75% + 75 ppm

Specifications calculated

Dew point temperature

Range:	-44 ° C to 50 ° C
Display resolution:	0.1 ° C
Accuracy:	± 1 ° C Temperature: -20 ° C to 50 ° C RH: 40-90% ± 2 ° C Temperature: -20 ° C to 50 ° C RH: 20-40% ± 4 ° C RH: 10-20%

Wet bulb temperature

Range:	-16 ° C to 50 ° C
Display resolution:	0.1 ° C
Accuracy:	± 1.2 ° C RH: 20-90% Temperature: -20 ° C to 60 ° C ± 2.1 ° C RH: 10-20%

Speed (in a pipe)

Range:	0 to 3.965 m3 / m (0 to 140 000 ft3/min)
Display resolution:	0.001 m3/min (1 ft3/min)
Accuracy:	N / A: The flow calculation isa simple average of the durations of data points in the area of the pipe

% Outside air (depending on temperature)
