The essential complement to your digital or analog oscilloscopes Class 1!
To view signals not referenced to ground, our models of differential probes are destined for use independently or in combination with mechanically MTX oscilloscopes. The MTX 1032 work with banana test leads or coaxial / banana long (depending on model).

MTX 1032-C
  • Bandwidth: 50 MHz
  • Compliance until 600V/Cat. II
  • Use with coaxial / banana and probes for oscilloscopes

    MTX 1032-B
  • Bandwidth: 30 MHz
  • Compliance until 600V/Cat. III
  • Using games with banana leads

    Common features:
  • Input: 2-Way Differential / coaxial connectors
  • Range of input differential voltage: ± 0.1V to ± 400V
  • Mains
  • Conform to safety standards according to IEC 61010-1 DBT
  • EMC: EN 61326-1 (07/97) + A1 (10/98) + A2 (2001)
  • Dimensions: 270 x 250 x 63 mm
  • Weight: 1.2 kg
